小型打樣熱銷款輥筒印花機

Item NO.:

BA20120

First name:

Auto Heat-transfer Machine for Lanyard, Webbing, Label

Voltage:

1 Phase 220V 50HZ

Dimension:

Machine: L228*W58*H135cm, Working Table: L90*W152*H100cm

Color:

Red or Blue

Power:

5.5KW

Roller Width:

1200mm

Roller Diameter:

200mm

Temp.Range:

0-300°C

Noise:

30QB

Speed:

120-150m/h, 144-180m2/h,1152-1440 m2/d

Package Size:

L200*W104*H142cm,

Packing

Wooden Box, 1set machine + 1set working table

Installation size:

L248*W148*W135cm,

N.W.:

350KG

G.W:

450KG

• Independent welding table, easy to install and remove;
• Adjustable torque put paper roller, paper conveying stable balance;
• Anti-pinch device to ensure safe operation;
• Microcomputer operation panel, simple and reliable;
• High burning point conveyor blankets, flame retardant performance; blanket thickness uniformity, the transfer effect is good;
• Teflon coating heating roller, effectively prevent electrostatic interference in the transfer process, roller temperature is small;
• Brand conductive oil, heat stable and uniform;
• Adjustable blanket roller rack pressure mechanism, pressure adjustment is simple and convenient;
• Brand electrical components, long life, low failure rate;
• PVC conveyor belt, isolation paper reel, ribbon drive shaft speed can be independently flexible adjustment;
• Independent blanket correction structure;
• Special small diameter roller design, machine covers an area of small;
• Tension adjustment structure, to ensure that the cloth and paper transfer process of tension balance.
